StarTech.com SV231DPDDUA2 - Introduction and Product Overview; Product Diagram

Instruction manual
1
Introduction
You can use the SV231DPDDUA2 to control two computers enabled with DisplayPort™
1.2, and share USB 2.0 peripherals among the connected computers.
If you connect monitors enabled with DisplayPort 1.2, the SV231DPDDUA2 supports
4K at 60Hz. This two-port dual monitor KVM switch includes 3.5 mm audio speaker
and microphone ports, and a select button that you can use to quickly switch between
connected computers. SV231DPDDUA2 also features support for hotkey commands.
Product diagram
Front view
Computer 1
LED
Computer 2
LED
Select button
Back view
1 - Power input port
2 - Console audio port
3 - Console microphone port
4 - Console DisplayPort port
5 - Console DisplayPort port
6 - Console USB mouse port
7 - Console USB keyboard port
8 - USB hub port
9 - USB hub port
10 - PC 2 USB port
11 - PC 2 DisplayPort port
12 - PC 2 DisplayPort port
13 - PC 2 audio port
14 - PC 2 microphone port
2
4
5
1
3
7
8
9
6
10
11
13
12
14
17
16
15
18
19
15 - PC 1 DisplayPort port
16 - PC 1 DisplayPort port
17 - PC 1 USB port
18 - PC 1 audio port
19 - PC 1 microphone port
