StarTech.com SV231DPDDUA2 User Manual

Instruction manual
2
Package contents
• 1 x KVM switch
• 1 x universal power adapter (NA, EU, UK, ANZ)
• 4 x rubber pads
• 1 x instruction manual
System requirements
• Display device (for example, monitor, TV, and so on) equipped with DisplayPort 1.2
• Computer system and video card enabled with DisplayPort 1.2
• Computer system enabled with USB
• Standard 104-key wired USB keyboard
• Standard wired USB mouse
• 3.5 mm mini-jack microphone and/or speakers or headset (optional)
Note: This KVM switch supports DisplayPort 1.2 and earlier. However, to achieve
maximum resolution, you need to use a display device and computer system that
support DisplayPort 1.2.
The maximum resolution for this KVM switch is 4K at 60Hz. In order to obtain the
maximum resolution, the monitor and computer that you’re using must support 4K at
60Hz.
System requirements are subject to change. For the latest requirements, please visit
www.StarTech.com/SV231DPDDUA2.

StarTech.com SV231DPDDUA2 Specifications

General

IP control	No
Audio support	Yes
Maximum resolution	3840 x 2160 pixels
Certification	CE, FCC, REACH, TAA
Product color	Black
Rack mounting	-
Console ports	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
USB connector type	USB Type-A
Console USB ports quantity	4
Number of microphone inputs	3
Number of computers controlled	2
Input current	1.5 A
Output current	0.6 A
Output voltage	12 V
Compatible power plug types	AU, EU, UK, US
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Package depth	249 mm
Package width	186 mm
Package height	97 mm
Package weight	1200 g
Sustainability certificates	RoHS
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	58 mm
Width	161 mm
Height	100 mm
Weight	734 g
