SteelFlex XT-2700 - Belt Tensioning; Adjusting Running Belt Tension

XT-3200/3300/3600/4600
4800/5600/5700 Treadmill
BELT TENSION INSTRUCTIONS
make 3 turns
After assembly and before turning
power on position the rear roller
using the " T " wrench (refer to the
drawing if needed). make 3 turns.
Clockwise to avoid the belt from
slipping.
If belt is too far to the left side
1) turn the left roller bolt 1/4 turn
clockwise(tighten)
2) turn the right roller 1/4 turn
counterclockwise(loosen)
If belt is too far to the right side
1) turn the right roller bolt 1/4 turn
clockwise(tighten)
2) turn the left roller bolt 1/4 turn
counterclockwise(loosen)
7
