Software
UR816C Operation Manual 16
Hardware Setup Window
This window allows you to configure general hardware
settings and Cubase-linked function settings.
1 model
Displays the name of the device.
2 HPF
Selects the cutoff frequency of the high pass filter.
Settings: 120Hz, 100Hz, 80Hz, 60Hz, 40Hz
3 Digital Mode
Selects the input and output signal format of the
[OPTICAL IN] and [OPTICAL OUT] jack.
When ADAT is selected, the input and output signals of up
to eight channels at 44.1 kHz and 48 kHz, or up to four
channels at 88.2 kHz and 96 kHz, or up to two channels at
176.4 kHz and 192 kHz. When S/PDIF is selected, the
input and output signals of up to two channels at any
available sample rate.
4 Scene
Automatically applies scene information to the UR816C
device when loading a Cubase project file containing
UR816C scene data.
NOTICE
Data saved to the device will be overwritten.
5 Channel Link
Automatically configures stereo links based on the bus
configuration in use.
Options Description
ADAT Input and output signals of up to 8 channels.
S/PDIF Input and output 2 channel signals.
