Appendix
UR816C Operation Manual 46
Digital I/O Interface
ADAT ADAT, Optical, 24-bit
S/PDIF IEC-60958, Optical, 24-bit
PHONES 1, 2
Maximum Output Level 100 mW+100 mW, 40 Ω
USB
Specification USB 3.0, 32-bit, 44.1 kHz/48 kHz/88.2 kHz/96 kHz/176.4 kHz/192 kHz
MIDI
MIDI IN, OUT DIN 5pin
WORD CLOCK
WORD CLOCK IN, OUT TTL/75 Ohm
XLR INPUT
Polarity 1: Ground
2: Hot (+)
3: Cold (-)
