Specifications 21
Chapter 4 - Specifications
Model 14528 Crane
SPECIFICATION SHEET
Crane Rating: 70,000 ft-lbs (9.68 ton-meters)
Standar
d Boom Length: 13’ (3.96 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 90" (228.6 cm)
2nd stage: Hydraulic 90" (228.6 cm)
Maximum Horizontal Reach: 28’ (8.53 m) from CL of Crane
Maximum Vertical Lift: 29’ 4” (8.94 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height: 43” (102.9 cm)
(crane only)
Mounting Space Required: 25” x 22” (63.5 x 55.9 cm)
Approximate Shipping Weight: 3100 lbs (1406 kg)
Controls: Radio control standard for all functions.
Winch Specifications
Rope Diameter: 1/2" (1.27 cm)
Line pull speed: 60 ft/min (18.29 m/min)
Max. single part line: 7000 lbs (3175 kg)
Max. double part line: 14,000 lbs (46,350 kg)
Rotation: 400 degree power
(worm gear)
Lifting Capacities: 5375 lbs @ 13’ (2440 kg @ 3.96 m)
2500 lbs @ 28’ (1130 kg @ 8.54 m)
Power Supply Required: PTO & Pump
(12 gpm @ 2600 psi)
(45.4 lpm @ 180 bars)
*Subject to change without notification
