stellar labs Flex36 60-8 - Port Side Relief Installation

Installation 29
MAIN CYLINDER
RETRACT PORT
PLUG
PORT SIDE RELIEF
MAIN RELIEF
VALVE BANK
• For some options, port side relief is required.
• To install port side relief:
1. Remove plug.
2. Insert relief.
3. Replace plug
• Relief can be installed on the retract or extend side of the valve bank.
Port Side Relief Installation
