Specifications
Chapter 1 - Specifications
Model 7628 Crane
SPECIFICATION SHEET
Crane Rating: 38,000 ft-lb (5.25 TM)
Standard Boom Length: 12’6” (3.81 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 90"(228.6 cm)
2nd stage: Hydraulic 90"(228.6 cm)
Maximum Horizontal Reach: 28’6” (8.69 m) from CL of Crane
Maximum Vertical Lift: 30’4” (9.24 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height 35.50” (90.2 cm)
(crane only)
Mounting Space Required 20 x 21 inches (50.8 x 53.3 cm)
Approximate Crane Weight 1900 lbs (885 kg)
Controls Radio control standard
for all functions.
Winch Specification
Rope Diameter: 3/8"(.952 cm)
Line pull speed: 60 ft/min (18.29 m/min)
Max. single part line: 3750 lbs (1700 kg)
Max. double part line: 7500 lbs (3400 kg)
Rotation: 400 degree power
(worm gear)
Lifting Capacities 3040 lbs @ 12’6” (375 kg @ 3.81 m)
1335 lbs @ 28’6” (605 kg @ 8.69 m)
Power Supply Required PTO & Pump
(8 gpm @ 3000 psi)
(30.3 lpm @ 207 bar)
*Subject to change without notification
