7. Place all the wires into the connection box.
8. Align the little slots located on the top of the thermostat with those on the the mounting base and
secure the thermostat to the mounting base. Note that you can also position the thermostat on
the left or the right side of the junction box (see the illustrations below). Then, tighten the screw
at the bottom of the unit.
9. Turn on the power.
ALIGNMENT
