CROSS REFERENCE TABLE
Ki Z-Wave protocol
Comfort Heat (1)
Eco (
) Energy Save Heat (11)
Z-Wave connectivity
If the thermostat is added (Included) to a Z-Wave network, the connectivity icon will be displayed on the
LCD, if the device is removed (Excluded) from a Z-Wave network, the connectivity icon
will disappear.
The connectivity icon
may blink if there is an issue with the Z-Wave radio circuit.
Advanced settings ( )
There are 6 advanced settings menus on the thermostat.
The advanced settings are the following:
1. Z-Wave menu
: used to add (include) or remove (exclude) the thermostat from a Z-Wave
network
2. Display format: used to switch the temperature format between °C and °F
3. Lock mode
: used to lock the thermostat to prevent unauthorized tampering.
4. Outdoor temperature display
: used to switch the outdoor temperature display on or off
(when available). When set to On, the outdoor temperature will be displayed if it’s available.
When set to Off, the outdoor temperature will not be displayed and set point will always be
displayed.
5. Backlight status
while idle: used to set the backlight intensity when the thermostat is idle.
0%: the backlight will turn off after 15 seconds of inactivity
50%: the backlight will dimmed to 50% after 15 seconds of inactivity
100%: the backlight will always be at full intensity
