Stelpro STZW402+ - Wire Installation

040D05A_INSSTZW402+1215
5
6. Pass the wires from the wall through the hole at the base of the mounting base and connect them
using the supplied solderless connectors. When making the connection with aluminum wire,
make sure that you are using connectors identified CO/ALR. Please note that the thermostat
wires do not have polarity. Therefore, the way they are connected is not important.
2-WIRE INSTALLATION
4-WIRE INSTALLATION
