STEPCRAFT MM-800 - Technical Data

-4-
2.3 Technical data
MM-800
MM-1000
MM-1000
MM-1000 DI
Universal motor, radio /
TV Interf. suppressed
230 V~, 50 Hz
230 V~, 50 Hz
120 V~, 60 Hz
230 V~, 50 Hz
Power input (nominal
load)
800 W
1000 W
1000 W
1000 W
Current at nominal load
4.0 A
4.6 A
8.3 A
4.6 A
Idling speed
7.000 – 25.000
min
-1
4.000 – 25.000
min
-1
10.000 – 25.000
min
-1
4.000 – 25.000
min
-1
Tool holding fixture with
collet ø
3,175 mm
3,175 mm
3,175 mm
3,175 mm
Tool shank max
Tool shank min
8 mm
3 mm
8 mm
3 mm
8 mm
3 mm
8 mm
3 mm
Milling cutter Ø, max
36 mm
36 mm
36 mm
36 mm
Abrasive wheel Ø, max
40 mm
40 mm
40 mm
40 mm
Weight without mains
cable
1,6 kg
1,6 kg
1,6 kg
1,65 kg
Dimensions (W x L x H)
73 x 254 x 79 mm
(2.87 x 10 x 3.11
in.)
73 x 254 x 79 mm
(2.87 x 10 x 3.11
in.)
73 x 254 x 79 mm
(2.87 x 10 x 3.11
in.)
73 x 254 x 79 mm
(2.87 x 10 x 3.11
in.)
Fig. 1
1
Spindle
2
Precision collet
3
Unit nut
4
Spindle lock
5
Switch
1
2
3
