-5-
Fig. 2
2.4 Emissions
The values stated are emission levels. Although there is a correlation between emission and imission level, it
cannot be reliably derived from this whether additional precautions are necessary. Factors influencing the
current immission level existing at the workplace comprise the duration of exposure, the room characteristic,
other source of noise, etc. such as e.g. the number of machines and other adjacent machining operations. In
addition, the permissible immission level may differ from country to country. This information is nevertheless
suitable for providing the machine user with an improved assessment of the hazard and risk.
2.4.1 Noise emission specifications
Noise emission values determined according to DIN EN ISO 3744:
Sound pressure level L
PA
= 71 dB (A)
PA
Sound power level L
PA
= 82 dB (A)
Uncertainty K
PA
= 3 dB (A)
The noise measurement was done without tool at idling speed.
2.5 Scope of delivery
Milling motor MM-800 / MM-1000 / MM-1000 DI complete with:
1 collet OZ
1 open-ended spanner AF 17
1 operating manual
2.6 Use according to intended purpose
- The power tool is intended for permanent installation in guiding portal systems with ø 43 mm clamping
collar.
- The power tool with quick tool clamping can be flanged directly to a portal system using six screws (M6
thread) according to the specifications of the portal system (Fig. 5).
- The power tool is not designed for continuous industrial operation.
- The power tool is considered an incomplete machine. The power tool must not be put into operation until it
has been established that the portal system in which the power tool is to be installed complies with the
provisions of the current and valid Machinery Directive. Please also observe the corresponding warranty
conditions for the power tool and any additional equipment.
