Stephan Alia - Pneumotachograph Type D; Pneumotachograph Typ C

3 Components and functions
44 SA-112-0106V1.0-WEM-GB © F. Stephan GmbH
3.6.4 Pneumotachograph type D
The pneumotachograph type D measures the inspired and expired flow
(> 25 l/min) and is used together with a patient tube system for adults.
Fig. 39: PNT D
3.6.5 Pneumotachograph Typ C
The pneumotachograph type C measures the inspired and expired flow
(> 25 l/min) and is used together with a patient tube system for children.
Fig. 40: PNT C
