ENGLISH
93
CAUTION Burns
If the water supplied to the appliance is preheated, the
internal anti-scalding protection and the temperature
limit that is adjustable by the user may be exceeded.
In such cases, limit the temperature with an upstream
central thermostatic valve (ZTA 3/4).
Anti-scalding protection deactivation
Proceed as described under "Anti-scalding protection acti-
vation". Deactivate anti-scalding protection by tapping the
"Active" tick symbol (deactivate).
14.2 Electrical connection from above on unfinished
walls
D0000053282
1
1 Cable routing
Reposition the mains terminal from the bottom to the top. To
do this, undo the fixing screw. Turn the mains terminal with
connecting cables 180° clockwise. Route the cable around
the cable guide when doing so. Secure the mains terminal in
place.
Replace the cable grommets by removing both cable
grommets.
Install the cable grommet from the top at the bottom.
Route the other cable grommet over the cable sheath of the
power cable. Pull the cable grommets into the back panel
until both locking tabs engage.
Install the appliance on the threaded studs of the wall
mounting bracket.
Push the back panel firmly against the wall. Lock the fixing
toggle by turning it 90° clockwise.
Pull the cable grommets into the back panel until both lock-
ing tabs engage.
Connect the power cable to the mains terminal.
