39
10.7 Available external head of the circulation pump
0
100
200
300
400
500
600
700
800
900
0 0,2 0,4 0,6 0,8 1 1,2 1,4 1,6 1,8
D0000039604
X Flow rate [m
3
/h]
Y Pressure [hPa]
1 Pump rate 100 %
2 Pump rate 85 %
3 Pump rate 65 %
4 Pump rate 45 %
10.8 Fan curve
0
20
40
60
80
100
120
140
160
180
200
220
80 100 120 140 160 180 200 220 240 260 280 300 320
1
2
0,30
0,35
0,40
0,45
0,50
D0000042009
Application range
X Air flow rate [m³/h]
Y Average value, static pressure [Pa]
1 Maximum fan curve
2 System curves
0.30 Specific power consumption 0.30 Wh/m³
0.35 Specific power consumption 0.35 Wh/m³
0.40 Specific power consumption 0.40 Wh/m³
0.45 Specific power consumption 0.45 Wh/m³
0.50 Specific power consumption 0.50 Wh/m³
0.55 Specific power consumption 0.55 Wh/m³
