STIEBEL ELTRON WPM Installation

INSTALLATION
Electrical connection
www.stiebel-eltron.com WPM | 17
ENGLISH
Safety extra low voltage
X1.1
CAN A
+
-
L
H
+
-
L
H
CAN (connection for heat pump and WPE heat
pump extension)
X1.2
CAN B
+
-
L
H
+
-
L
H
CAN (connection for FET remote control and
ISG Internet Service Gateway)
X1.3 Signal
Earth
1
2
Outside temperature sensor
X1.4 Signal
Earth
1
2
Buffer sensor (heating circuit sensor 1)
X1.5 Signal
Earth
1
2
Flow sensor
X1.6 Signal
Earth
1
2
Heating circuit sensor 2
X1.7 Signal
Earth
1
2
Heating circuit sensor 3
X1.8 Signal
Earth
1
2
DHW cylinder sensor
X1.9 Signal
Earth
1
2
Source sensor
X1.10 Signal
Earth
1
2
Heat generator 2
X1.11 Signal
Earth
1
2
Cooling flow
X1.12 Signal
Earth
1
2
DHW circulation sensor
X1.13 Signal
Earth
Signal
1
2
3
FE7 remote control/ telephone remote
switch/ heating curve optimisation/ SGReady
X1.14 Constant 12V
Input
GND
+
IN
Analogue input 0-10V
X1.15 Constant 12V
Input
GND
+
IN
Analogue input 0-10V
X1.16 Signal
Earth
1
2
PWM output 1
X1.17 Signal
Earth
1
2
PWM output 2
X1.18
CAN B
+
-
L
H
+
-
L
H
CAN (connection for FET remote control and
ISG Internet Service Gateway)
X1.19
CAN A
+
-
L
H
+
-
L
H
CAN (connection for heat pump and WPE heat
pump extension)
Mains voltage
X2.1 L
L
N
N
PE
PE
L
L
N
N
Power supply
X2.2 L' (power supply
utility input)
L* (pumps L)
L'
L* (pumps L)
L' (power supply utility input)
L* (pumps L)
X2.3 L
N
PE
L
N
PE
Heating circuit pump 1
X2.4 L
N
PE
L
N
PE
Heating circuit pump 2
X2.5 L
N
PE
L
N
PE
Heating circuit pump 3
X2.6 L
N
PE
L
N
PE
Buffer charging pump 1
X2.7 L
N
PE
L
N
PE
Buffer charging pump 2
X2.8 L
N
PE
L
N
PE
DHW charging pump
X2.9 L
N
PE
L
N
PE
Source pump/defrost
X2.10 L
N
PE
L
N
PE
Fault output
X2.11 L
N
PE
L
N
PE
DHW circulation pump/ 2nd heat
source DHW
X2.12 L
N
PE
L
N
PE
2ndheat source heating
X2.13 L
N
PE
L
N
PE
Cooling
X2.14 Mixer OPEN
N
PE
Mixer CLOSE
5
N
PE
6
Mixer heating circuit 2
( X2.14.1 Mixer OPEN
X2.14.2 Mixer CLOSE )
X2.15 Mixer OPEN
N
PE
Mixer CLOSE
5
N
PE
6
Mixer heating circuit 3
( X2.15.1 Mixer OPEN
X2.15.2 Mixer CLOSE )
Note
For every appliance fault, output X2.10 issues a 230V
signal.
In the case of temporary faults, the output switches the
signal through for a specific time.
In the case of faults that result in a permanent appliance
shutdown, the output switches through permanently.
 You can define the characteristics of the output via
parameter "COMMISSIONING/ I/O CONFIGURATION/
OUTPUT X 2.10".
