Indicator light ON: cutting devices engaged
(Fig. 16.A).
Indicator light ON: parking brake engaged
(Fig. 16.B).
Indicator light ON: operator not present
(Fig. 16.C).
Fuel indicator light with level indicator (Fig. 16.D)
Fuel level is in reserve.
level and contact an Authorized Service Centre.
Indicator light ON: Grass catcher or rear
Indicator light ON: when the engine is running
an Authorized Service Centre (Fig. 16.G).
Indicator light ON: transmission
in “neutral” (Fig. 16.H).
Hour meter (Fig. 16.I). Indicates the total
Voltmeter (Fig. 16.O). Indicates
engine speed as numerical values or a
< 1600 engine idling speed
< 2500
> 2500 cutting speed
*
engine idling speed
**
***
****
*****
******
cutting speed
NOTE The flashing light indicates that the current engine
speed is unsuitable for mowing grass.
Acoustic signals - Buzzer
1. Continuous
acoustic signal:
• Electronic card protection
•
in the “DRIVE” position.
2. Intermittent
acoustic signal:
•
•
Icon ON: cutting devices engaged (Fig. 16.A).
Icon ON: parking brake engaged (Fig. 16.B).
Indicator light ON: operator
not present (Fig. 16.C).
Fuel icon with level indicator (Fig. 16.D)
Fuel level is in reserve.
contact an Authorized Service Centre.
