EN - 18
For Best Mowing Results
• Cut grass when it is dry.
• Keep mower blades sharp.
• Keep mower deck properly levelled.
• Do not set height of cut too low. For very
tall grass, mow twice.
• Do not travel too fast.
• Mow with the engine set at full throttle.
• When mulching, only remove 1/3 of grass
length per cutting. Do not cut more than
2.5 cm (1") at any one time.
• Discharge clippings into areas already cut.
• Vary cutting pattern with each mowing.
• Do not allow grass or debris to collect
inside of mower deck. Clean after each
use.
STOP THE ENGINE
1. Move steering levers to neutral position.
2. Engage parking brake.
3. Push PTO knob down to off position.
4. Set throttle to slow speed.
5. Turn ignition key to off position and
remove key from ignition.
MOVE UNIT MANUALLY
See Figure 17.
IMPORTANT: There is one transaxle bypass
lever on each side of unit. Ensure that both
levers are fully in front or rear position.
• To disengage the transaxles and move unit
with the engine off, place both bypass
levers in the rear position.
• To engage transaxles and operate unit
normally, place both bypass levers in the
front position.
TRANSPORT UNIT
1. Stop engine, set parking brake and
remove key from ignition.
2. Secure unit chassis to transport vehicle.
NOTICE: NEVER secure from rods or
linkages that could be damaged.
WARNING: AVOID INJURY.
Wait for all moving parts to
stop before leaving operator’s
position.
Figure 17
Front Position
Rear Position
