Technical Information 11.2013 Page 5
TI_11_2013_30_01_01.fm
5. Specifications
5.1 Engine
5.2 Ignition System
5.3 Fuel System
5.4 Chain Lubrication
5.5 Weight
5.6 Cutting Attachment
5.6.1 STIHL ROLLOMATIC
®
Guide Bars
5.6.2 OILOMATIC
®
Saw Chain
5.6.3 Chain Sprockets
STIHL single cylinder two-stroke engine
Model MS 362 C-M
Displacement: 3.6 cu.in (59.0 cc)
Bore: 1.85 in (47 mm)
Stroke: 1.34in (34mm)
Engine power to ISO 7293: 4.7 bhp (3.5 kW) at 10,000 rpm
Max. torque (rated): 2.66 lbf.ft (3.6 Nm) at 7,000 rpm
Idle speed: 2,800 rpm
Cut-off speed: 14,000 rpm
Spark plug (resistor type): Bosch WSR 6 F,
NGK BPMR 7 A
Electrode gap: 0.020 in
(0.5 mm)
All position diaphragm carburetor with integral fuel
pump
Fuel tank capacity: 20.3 fl.oz. (0.6 l)
Fully automatic speed controlled oil pump –
additional manual oil flow control.
Oil tank capacity: 11.0 fl.oz. (0.325 l)
Weight (dry, without bar and chain)
–MS362C-M:
12.8 lbs (5.8 kg)
–MS362C-MQ
with STIHL Quickstop
®
Plus
13.0 lbs (5.9 kg)
– MS 362 C-M R with wrap-
around handle:
13.5 lbs (6.1 kg)
Reduced kickback STIHL guide bars (with green
label)
Bar lengths
(3/8" pitch):
15, 16, 18, 20 in
(37, 40, 45, 50 cm)
Groove width: 0.036 in (1.6 mm)
Nose sprocket: 11-tooth
Low kickback STIHL saw chain
(with green label)
STIHL RAPID™ Micro 3 (33 RM3)
STIHL RAPID™ Super 3 (33 RS3)
Pitch: 3/8" (9.32 mm)
Drive link gauge: 0.036 in (1.6 mm)
STIHL RAPID™ Micro (33 RM)
STIHL RAPID™ Super (33 RS)
Pitch: 3/8" (9.32 mm)
Drive link gauge: 0.050 in (1.3 mm)
7-tooth for 3/8" (spur/rim sprocket)
