Stihl FS 510 C-M User Manual

FS 510 C-M, FS 560 C-M
English
30
N Depress in the outer edge (arrows)
of the choke knob (5) and then turn
it to Start }.
Cranking
N Place the unit on the ground: It must
rest securely on the engine's guard
plate and the deflector. Check that
the cutting attachment is not
touching the ground of any other
obstacles.
N Make sure you have a firm footing –
either standing, stooping or
kneeling.
N Hold the unit firmly on the ground
with your left hand and press down
– do not touch the throttle trigger or
lockout lever.
Do not stand or kneel on the drive tube.
N Hold the starter grip with your right
hand.
Alternative method of starting:
With the machine suspended from the
harness and the engine at normal
operating temperature:
N Hold the machine firmly with your
right hand on the drive tube, handle
support or handlebar.
N With the machine behind you, press
it against the left side of your body.
N Hold the starter grip with your left
hand.
N Pull the starter grip steadily.
Do not pull out the starter rope all the
way – it might otherwise break.
N Do not let the starter grip snap back.
Guide it slowly back into the housing
so that the starter rope can rewind
properly.
N Continue cranking until the engine
runs.
As soon as the engine runs
N Make sure the engine runs
smoothly.
If the engine stalls:
N Continue cranking until the engine
runs.
As soon as the engine runs smoothly
N After a cold start, allow the engine to
warm up in the Start } position.
Machine is ready for use.
If you have started the machine for the
first time, refer to the notes on "Starting
for first time" in section "Other Hints on
Starting".
N Depress throttle trigger lockout and
pull the throttle trigger – the choke
knob moves to the Run F position.
The cutting attachment must not rotate
in the Run F position with the engine at
idling speed.
5
4900BA018 KN
6BA011 KN
6BA012 KN
6BA010 KN
6BA014 KN
