Stihl FS 55R User Manual

FS 55, FS 55 C, FS 55 R, FS 55 RC
English
19
Mounting the Loop Handle with
Barrier Bar
N Fit the square nuts (1) in the barrier
bar (2); the holes must line up.
N Place the clamp (3) in the loop
handle (4) and position them both
against the drive tube (5).
N Place the clamp (6) against the
drive tube.
N Place the barrier bar (2) in position
as shown.
N Line up the holes.
N Insert the screws (7) and tighten
them down moderately against the
barrier bar.
N Go to "Securing the Loop Handle".
Mounting the Loop Handle without
Barrier Bar
N Place the clamp (3) in the loop
handle (4) and position them both
against the drive tube (5).
N Place the clamp (6) against the
drive tube.
N Line up the holes.
N Fit washers (7) on the screws (8)
and insert the screws in the holes.
Fit the square nuts (1) and screw
them down as far as stop.
N Go to "Securing the Loop Handle".
Mounting the Loop Handle
2
002BA098 KN
1
1
5
4
002BA099 KN
2
3
6
7
4
5
002BA136 KN
1
6
1
3
8
7
8
7

Stihl FS 55R Specifications

General

Displacement	27.2 cc
Power Output	0.75 kW
Engine Power	1.0 bhp
Fuel Capacity	0.33 L
Fuel Tank Capacity	0.33 L
Starter System	Recoil
Cutting Diameter	420 mm
Overall Length	1.7 m
Shaft Type	Straight
Cutting Width	23 cm
Engine Type	2-stroke gasoline engine
