FS 55, FS 55 C, FS 55 R, FS 55 RC
English
21
N Loosen the screw (3).
Floating position
N Mowing heads and grass cutting
blades should just touch the ground.
Proceed as follows to adjust the floating
position:
N Move the carrying ring up or down
the drive tube – tighten the screw
moderately – let the unit go and wait
until is its balanced – then check the
floating position.
When the correct floating position has
been reached:
N Tighten down the screw on the
carrying ring firmly.
Detaching the unit from the harness
N Press down the bar on the
carabiner (1) and pull the carrying
ring (2) out of the carabiner.
Version with bike handle
Controls
1 Throttle trigger lockout
2 Throttle trigger
3 Slide control
Positions of slide control
4 START – the ignition is switched on
– the engine can start
5 F – normal run position – the engine
is running or can start
6STOP-0 – engine off – the ignition is
switched off
