Stihl FS 55R User Manual

FS 55, FS 55 C, FS 55 R, FS 55 RC
English
31
If there is a noticeable loss of engine
power
N Set the choke lever to g.
N Press in the tab (1) and swing the
filter cover (2) down.
N Clean away loose dirt from around
the filter.
N Remove the felt element (3) from
the filter housing (4) and replace it –
knock out or blow out as a
temporary measure – do not wash.
N Replace damaged parts.
N Fit the felt element (3) in the filter
housing (4).
N Close the filter cover so that it snaps
into position.
Exhaust emissions are controlled by the
design of the fundamental engine
parameters and components (e.g.
carburation, ignition, timing and valve or
port timing) without the addition of any
major hardware.
Cleaning the Air Filter
232BA017 KN
1
2
232BA018 KN
4
3
Engine Management

Stihl FS 55R Specifications

General

Displacement	27.2 cc
Power Output	0.75 kW
Engine Power	1.0 bhp
Fuel Capacity	0.33 L
Fuel Tank Capacity	0.33 L
Starter System	Recoil
Cutting Diameter	420 mm
Overall Length	1.7 m
Shaft Type	Straight
Cutting Width	23 cm
Engine Type	2-stroke gasoline engine
