-Preparations,see4.4.
•
Unscrewcylinderbasescrews.
Note:Thetwoscrewsattheback
arenotvisible.
-Drawcylinderoffpiston.
-Examinecylinderandreplaceif
necessary.
-Thematchingpistonmustal-
waysbefittedwheninstallinga
newcylinder.Newcylindersare
thereforeonlysuppliedwith
piston.
-Beforeremovingthepiston,de-
cidewhetherthecrankshaftmust
alsoberemoved.Thecrank-
shaftmustbeblockedbysliding
thewoodenassemblyblockbe-
tweenthepistonandcrankcase
inordertoremovetheclutchand
startercarrier.
-Removecylindergasket.
•
Prisethehooklesssnaprings
outoftheannulargrooves.
•
Pushpistonpin(1)outofthe
pistonwithassemblydrift(2)
11148934700.
Note:Ifthepistonpinisstuck,it
canbeloosenedbylightlytap-
pingtheassemblydriftwithaham-
mer.Thepistonmustbeheld
steadyduringthisprocesstoen-
surethatnojoltsaretransmittedto
theconrod.
-Removepistonfromconrodand
drawneedlecageoutofsmall
end.
•
Checkpistonringsandreplaceif
necessary,see4.6.
•
Thoroughlycleansealingarea
(1).
•
Wetneedlecage(2)withoiland
fititinthesmallend.
•
Lightlyheatpistontofacilitatein-
stallationandslipitoverthecon-
rod.
•
Noteinstalledpositionofpiston:
1=Marking
2=Flywheel
•
Pushassemblydriftthrough
pistonandsmallend(needle
cage)withthesmalldiameter
firstandlineupthepiston.
392RA033
VA
366RA066
VA
12
366RA068
1
2
VA
392RA034
1
2
VA
145RA080 VA
366RA067 VA 366RA070 VA
4.5 Cylinderandpiston
4.5.1 Removal 4.5.2 Installation
16

Stihl FS 85 Specifications

General

Engine Type	2-stroke
Displacement	25.4 cc
Weight	5.2 kg
Shaft Type	Straight
Starter	Recoil
Vibration Damping	Yes
Power Output	0.95 kW
Fuel Capacity	0.44 liters
