-Removerubberbuffer(AVsy-
stem)fromfanhousing,see9.1.
•
Removecirclipforoutputstubof
clutchdrumwithpliers(1)
08166101495.
•
Pressclutchdrumoutofdeep
grooveballbearingwithassem-
blydrift(1)11088934700.
•
Examineballbearingandre-
placefanhousingiffoundtobe
defective.
•
Pressclutchdruminasfaras
possiblewithassemblydrift(1)
11088934700.
Theremainingpartsareinstalled
inreverseorder.
392RA177
1
VA
392RA180
1
VA
11.4 Clutchdrum
392RA178
1
VA
392RA179
VA
