Note: The bearing must be pres-
sed in very quickly, as it imme-
diately absorbs heat and begins to
expand.
•
If the starter side of the crank-
case cannot be heated, press
the deep groove ball bearing in
as far as possible with press
arbor (1) 4119 893 7200.
- Heat area of bearing seat on
clutch side of crankcase to
approx. 120
°
C.
•
Press deep groove ball bearing
into crankcase by hand as far as
possible.
Note: The bearing must be pres-
sed in very quickly, as it imme-
diately absorbs heat and begins to
expand.
•
If the clutch side of the crank-
case cannot be heated, press
the deep groove ball bearing in
as far as possible with press
arbor (1) 4119 893 7200.
•
Insert the shorter stub of the
crankshaft into the deep groove
ball bearing on the starter side of
the crankcase.
•
Completely screw spindle (1) of
assembly tool 5910 890 2202
into sleeve (2) (left-hand thread).
•
Screw spindle (1) onto crank-
shaft stub (2) turning clockwise
as far as possible.
392RA044
2 1
VA
11
366RA094 VA
11
22
392RA045 VA
11
366RA092 VA
366RA093 VA
366RA095 VA
21

Stihl FS 85 Specifications

General

Engine Type	2-stroke
Displacement	25.4 cc
Weight	5.2 kg
Shaft Type	Straight
Starter	Recoil
Vibration Damping	Yes
Power Output	0.95 kW
Fuel Capacity	0.44 liters
