Stihl FSA 57 User Manual

0458-806-8621-B
3
English 3 Main Parts
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
NOTICE
Indicates a risk of property damage, including damage to the
machine or its individual components.
2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
3.1 Trimmer, Battery and Charger
1 Battery Compartment
Holds the battery.
2 Locking Lever
Secures the battery in the battery compartment.
3 Control Handle
Handle for the operator's rear hand.
4 Trigger Switch
Activates the cutting attachment when depressed.
5 Trigger Switch Lockout
Must be depressed while the retaining latch is unlocked
to allow activation of the trigger switch.
Refers to a designated chapter or sub-chapter in this
instruction manual.
3 Main Parts
1
2
#
#
#
3
4
8
10
9
11
7
6
5
12
15
13
18
14
16
17
0000-GXX-4806-A0

Stihl FSA 57 Specifications

General

Power source	Battery
Battery voltage	36 V
Type	-
Telescopic	Yes
Product color	Orange, White
Sound power level	89 dB
Vibration emission	4 m/s²
Sound pressure level	74 dB
Cutting diameter (max)	280 mm
Battery charger included	No
