HT 105, HT 134, HT 135
English
27
N Adjust the hip belt (3), both shoulder
straps (4) and the carrying strap (5).
Only versions with telescoping shaft
N Put the backpack carrying
system (1) on your back and adjust
it as described in the instruction
leaflet provided.
N Attach the carabiner (1) to the
carrying ring (2) on the shaft.
N Attach the pole pruner to the
carrying strap when cutting.
N Adjust the hip belt (3), both shoulder
straps (4) and the carrying strap (5).
N Squeeze the clip together to move it
up or down the shaft.
4
5
3
0000-GXX-1572-A0
2
3
1
0000-GXX-1573-A1
4
5
3
0000-GXX-1574-A0
0000-GXX-1575-A0
