HT 105, HT 134, HT 135
English
25
Left: Base of fuel cap is tilted – interior
marking (1) is aligned with the exterior
marking
Right: Bottom of the fuel cap in correct
position – inner mark is under the grip. It
does not align with the exterior marking
N Fit fuel cap and twist it
counterclockwise until it engages in
the seat of the filling port
N Continue to twist the fuel cap
counterclockwise (approx. 1/4 turn)
– this will twist the base of the cap
into the correct position
N Twist the fuel cap clockwise and
close it – see section "Closing"
The saw chain must always throw off a
small amount of oil.
NOTICE
Never operate without chain lubrication.
If the chain runs dry, the whole cutting
attachment will be irretrievably damaged
within a very short time. Always check
chain lubrication and the oil level in the
tank before starting work.
Every new chain has to be broken in for
about 2 to 3 minutes.
After breaking in the chain, check chain
tension and adjust if necessary – see
"Checking Chain Tension".
WARNING
Always shut off the engine and fit the
chain scabbard.
N Loosen the clamp nut half a turn
counterclockwise.
N Adjust the shaft to the required
length.
N Tighten the nut clockwise.
Checking Chain Lubrication
Adjusting the Telescoping
Shaft
0000097196_001
