3 Overview
– Instruction manual of the carrying system you are using
– User instructions for STIHL AR battery
– User instructions for AP belt bag with connecting cable
– Safety notes and precautions for STIHL AP battery
– Instruction manual for STIHL AL 101, 300, 500 chargers
– Safety information for STIHL batteries and products
with built-in batteries: www.stihl.com/safety-data-
sheets
2.2 Symbols used with warnings in the text
WARNING
This symbol indicates dangers that can cause serious
injuries or death.
► The measures indicated can avoid serious injuries or
death.
NOTICE
This symbol indicates dangers that can cause damage to
property.
► The measures indicated can avoid damage to property.
2.3 Symbols in Text
3.1 KombiEngine and Battery
1 Locking lever
The locking lever holds the battery in the battery
compartment.
2 Battery compartment
The battery compartment holds the battery.
3Cover
The cover is the placeholder for a Smart Connector 2 A.
4 Air filter
The air filter filters the air entering the engine.
5 Control handle
For operating, holding and controlling the KombiEngine.
This symbol refers to a chapter in this instruction
manual.
3Overview
1
2
3
5
10
7
8
9
6
11
12
13
14
4
15
18
16 17
0000097118_002
#
#
