Stihl MS 201 C-M User Manual

MS 201 C-M
English
29
Preparations
N Before fueling, clean the filler cap
and the area around it to ensure that
no dirt falls into the tank.
Always thoroughly shake the mixture in
the canister before fueling your
machine.
N Position the machine so that the
filler cap is facing up.
WARNING
In order to reduce the risk of fire and
personal injury from escaping gas vapor
and fumes, remove the fuel filler cap
carefully so as to allow any pressure
build-up in the tank to release slowly.
Opening
N Raise handle.
N Twist filler cap counterclockwise
(approx. 1/4 turn).
Markings on filler cap and housing must
align.
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank – leave
approx. 1/2" (13 mm) air space.
Closing
Handle is in an upright position:
N Position filler cap – markings on filler
cap and housing must align.
N Push the filler cap down as far as it
will go.
Fueling
0011BA043 KN
001BA236 KN
001BA232 KN
001BA234 KN
001BA237 KN
001BA234 KN

Stihl MS 201 C-M Specifications

General

Idle speed	3000 RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	400 mm
Product color	Black, Grey, Orange
Motor speed (max)	10500 RPM
Oil tank capacity	0.22 L
Fuel tank capacity	0.31 L
Engine displacement	35.2 cm³
Kickback protection	Yes
Engine power	2.4 hp
Power source	Gasoline
Sound power level	112 dB
Vibration emission	3.3 m/s²
Sound pressure level	99 dB

Weight and Dimensions

Weight	3900 g
