Stihl MS 201 C-M User Manual

MS 201 C-M
English
51
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Engine
Single cylinder two-stroke engine
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Chain Lubrication
Fully automatic, speed-controlled oil
pump. Additional manual oil flow control
Weight
Cutting Attachments
Recommended cutting attachments
conforming with the 45 degree
computed kickback angle requirement
of Section 5.11 of
ANSI/OPEI B175.1-2012 when used on
this model chain saw (see the chapter
on "Safety Precautions and Working
Techniques"):
Rollomatic E guide bars
Actual cutting length will be less than
listed bar length.
Saw chain 3/8" P
Chain sprocket
To comply with the 45 degree computed
kickback angle requirement of Section
5.11 of ANSI/OPEI B175.1-2012, use
replacement saw chains listed above or
elsewhere by STIHL as conforming with
that requirement when used on this
model chain saw or use saw chains
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Displacement: 2.15 cu.in
(35.2 cc)
Bore: 1.60 in (40 mm)
Stroke: 1.10 in (28 mm)
Engine power to
ISO 7293:
2.4 bhp (1.8 kW)
at 9,500 rpm
Idle speed: 3,000 rpm
Max. permissible
speed (with cutting
attachment): 14,000 rpm
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.02 in (0.5 mm)
Fuel tank capacity: 10.5 fl.oz (0.31 l)
Oil tank capacity: 7.4 fl.oz (0.22 l)
dry, without bar and chain
MS 201 C-M: 8.6 lbs (3.9 kg)
MS 201 C-EM with
ErgoStart: 8.8 lbs (4.0 kg)
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 30, 35, 40 cm (12, 14,
16 in.)
Pitch: 3/8" P (9.32 mm)
Groove width: 1.3 mm (0.050 in)
Sprocket nose: 9-tooth
Low kickback STIHL saw chain (with
green label)
Picco Micro 3 (63 PM3) Type 3636
Picco Super 3 (63 PS3) Type 3616
Picco Duro 3 (63 PD3) Type 3612
Pitch: 3/8" P (9.32 mm)
Drive link gauge: 1.3 mm (0.050 in)
6-tooth for 3/8" P (spur sprocket)

Stihl MS 201 C-M Specifications

General

Idle speed	3000 RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	400 mm
Product color	Black, Grey, Orange
Motor speed (max)	10500 RPM
Oil tank capacity	0.22 L
Fuel tank capacity	0.31 L
Engine displacement	35.2 cm³
Kickback protection	Yes
Engine power	2.4 hp
Power source	Gasoline
Sound power level	112 dB
Vibration emission	3.3 m/s²
Sound pressure level	99 dB

Weight and Dimensions

Weight	3900 g
