47
DEFRNLITESPTNOSVFIDAPLHUHRCS EN
0478 111 9935 B - EN
18.1 REACH
REACH is an EC Directive for the
registration, evaluation, authorisation and
restriction of chemicals.
Information on compliance with the
REACH Directive (EC) No. 1907/2006 is
available from www.stihl.com/reach.
18. Technical specifications
RM4.0R, RM4.0RT, RM4.0RV,
RM 4.0 RTP:
Serial number 6383
Engine, design 4-stroke com-
bustion engine
Fuel tank 1,4 l
Cutting utilities Cutter bar
Cutting width 53 cm
Safety device Motorstop
Starter Rope start
Tightening torque for
blade fastening
screw 60 - 65 Nm
Cutting height 30 - 70 mm
Weight RM 4.0 R 34 kg
Weight RM4.0RT 35kg
Weight RM4.0RV 36kg
Weight RM 4.0 RTP 44 kg
RM4.0R, RM4.0RT, RM4.0RV:
Engine type Kohler XT675
Fuel consumption 427 g/kWh
(average)
Displacement 149 ccm
Nominal output at
nominal speed
2,2 - 2800
kW - rpm
Engine output speed 2800 rpm
Speed of cutting
utilities 2800 rpm
Drive RM 4.0 RT Front wheel
1 forward gear
Drive RM 4.0 RV Front wheel
Vario
Wheel diameter
(front) 200 mm
Wheel diameter
(rear) 200 mm
Length 140 cm
Width 57 cm
Height 107 cm
Sound emissions:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
94 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
82 dB(A)
Uncertainty K
pA
1dB(A)
Hand-arm vibrations:
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
3,33 m/s
2
Uncertainty K
hw
1,67 m/s
2
Measurement in accordance with
EN 20643
RM 4.0 RTP:
Engine type Kohler XT8
Fuel consumption 441 g/kWh
(average)
Displacement 173 ccm
Nominal output at
nominal speed
2,6 - 2800
kW - rpm
Engine output speed 2800 rpm
Speed of cutting
utilities 2800 rpm
Drive Front wheel
1 forward gear
Wheel diameter
(front) 210 mm
Wheel diameter
(rear) 205 mm
Length 140 cm
RM4.0R, RM4.0RT, RM4.0RV:
Width 57 cm
Height 108 cm
Sound emissions:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
93 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
80 dB(A)
Uncertainty K
pA
1 dB(A)
Hand-arm vibrations:
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
2,40 m/s
2
Uncertainty Khw 1,20 m/s
2
Measurement in accordance with
EN 20643
19. Troubleshooting
# If necessary, contact a specialist
dealer; STIHL recommends STIHL
specialist dealers.
@ See engine instruction manual.
RM 4.0 RTP:

Stihl RM 4 R Specifications

General

Type	Walk behind lawn mower
Motor type	Single cylinder OHV
Cutting width	530 mm
Grass catcher	No
Product color	Black, Orange, White
Uncertainty K	1.6 m/s²
Ergonomic handle	Yes
Housing material	Steel
Number of wheels	4 wheel(s)
Rotational speed	2800 RPM
Maximum lawn area	1500 m²
Sound power level	93 dB
Handle(s) features	Soft grip
Vibration emission	3.2 m/s²
Engine displacement	149 cm³
Maximum cutting height	70 mm
Minimum cutting height	30 mm
Motor power	3 hp
Engine power	2200 W
Power source	Gasoline

Weight and Dimensions

Weight	34000 g
