0478-131-3045-A
81
English
25 Installation Examples
U-shaped mowing area with several free-standing trees:
– Docking station: Location(1) next to the house(A)
– Restricted area: Installation around the free-standing
trees, based on linking sections installed at right angles to
the perimeter of the mowing area(2), two restricted areas
are connected via a linking section.
– Swimming pool: Distance between perimeter wire(2) and
pool B: 3.3ft. (1m)
– Wire clearances:
– Clearance from obstacles which can be travelled on
such as patios and paths: 0in. (0cm)
– Clearance from high obstacles: 10.6in. (27cm)
– Clearance from the trees: 14.6in. (37cm)
– Programming: No further modification is necessary
following definition of the size of the mowing area.
– Particulars: Tree in the corner of the mowing area. Mow
the area behind the blocked-off tree regularly using a
suitable trimmer or other tool.
A
1
2
0000-GXX-3429-A0
