USG
USG with attachment for
Oilomatic saw chain
1 Motor
2 Switchbox
3 Attachment
4 Motor arm
5 Clamping lever
6 Thrust plate
7 Travel limiting screw
8 Stop
9 Adjusting screw
10 Grinding wheel
11 Stop lug
Attachment for
hedge trimmer blades
1 Star knob
2 Spring
3 Stop
4 Adjusting screw
5 Clamp
6 Angle iron rail
Attachment for
circular saw blades
1 Locator
2 Shoulder stud
3 Clamping lever
4 Adjusting screw
5 Stop
Main Parts of Sharpener
35
1
2
4
6
7
8
9
10
11
523BA133 KN
2
3
4
6
523BA132 KN
5
1
4
523BA134 KN
5
1
3
2
