4 Reverse indicator light Lights up when reversing normally.
5 Lifting indicator light Lights up when lifting normally.
6 Lowering indicator light Lights up when lowering normally.
7 Operating status indicator light
Lit solid, interlock switch off;
Flashing, interlock switch closed, hour me-
ter starts counting.
8 Information display area
Displays the vehicle’s total operating time;
Displays error messages.
Error code
Error codes
1
Control unit co-
des
2 = Drive control
unit
6 = Steering con-
trol unit
2 Error code
The correspond-
ing error mes-
sage can be
checked based
on the error code
Views
3
Display element
435001 801 1555 EN - 12/2020
