4.34.2
Aisle width for pallets 800 × 1200
lengthways
Ast mm 2208
4.35 Turning radius Wa mm 1390
Performance data
5.1 Travel speed, laden/ unladen km/h 5/5.5
5.2 Lifting speed, laden/ unladen m/s 0.028/0.031
5.3 Lowering speed, laden/ unladen m/s 0.068/0.043
5.8 Max. gradeability, laden/unladen % 8/20
5.9 Acceleration time, laden/unladen s 10.78/9.88
5.10 Service brake type Electromagnetic
Electric-engine
6.1 Drive motor rating S2 60 min kW 0.9
6.2 Lift motor rating at S3 15% kW 0.8
6.3
The maximum allowed size bat-
tery
mm 270*110*440
6.4
Battery voltage/nominal capacity
K5
V/Ah 48V*1/20ah(/30Ah)
6.5 Battery weight kg 10.5*1
6.6
Energy consumption according to
VDI cycle
kWh/
h
0.239
Other data
8.1 Type of drive control DC
10.5 Steering type Mechanical
10.7
Sound pressure level at the driv-
er’s ear
dB
(A)
<70
Eco-design requirements for
electric motors and variable
speed drives
All motors in this industrial truck are exempt
from Regulation (EU) 2019/1781 because
these motors do not meet the description giv-
en in Article 2 "Scope", Item (1) (a) and be-
cause of the provisions in Article 2 (2) (h) "Mo-
tors in cordless or battery-operated equip-
ment" and Article 2 (2) (o) "Motors designed
specifically for the traction of electric vehicles".
All variable speed drives in this industrial truck
are exempt from Regulation (EU) 2019/1781
because these variable speed drives do not
Technical data
9
Eco-design requirements for electric motors and variable speed drives
90 5001 801 1555 EN - 12/2020
