1.2 Model no. ECH15
1.3 Drive type Battery
1.4 Operation type pedestrian
1.5 rated capacity Q kg 1500
1.6 Load centre distance c mm 600
1.8 Load distance x mm 946/883
1.9 Wheelbase y mm 1200/1135
Weight
2.1 Service weight （include. battery) kg 180
2.2
Axle loading, laden driving side/
loading side
kg 606/1076
2.3
Axle loading, unladen driving
side/loading side
kg145/35
Tyres, Chassis
3.1
Type of tyre, drive wheel/load
wheel:
PU/PU
3.2
Tyre size, driving wheels（diam-
eter×width）
mm Ф210x70
3.3
Tyre size, loading wheels（diam-
eter×width）
mm Ф80x60(Ф74x88）
3.4
Tyre size, caster wheels（diame-
ter×width）
mm Ф74 x 30
3.5
Wheels, number driving，caster/
loading (x= drive wheels)
mm 1 x 2/4 (1 x 2/2)
3.6 Track width, front, driving side b10 mm 450
3.7 Track width, rear, loading side b11 mm 390
Dimensions
4.4 Basic model, maximum lift height h3 mm 115
4.9
Height of handle in operating po-
sition, min/max
h14 mm 700/1200
4.15 Fork height lowered h13 mm 80
4.19 Overall length l1 mm 1550
4.20 Length to vertical face of fork l2 mm 400
4.21 Total width
b1/b
2
mm 620/705
4.22 Fork dimensions s/e/l mm 50/150/1150
4.23 Vehicle height mm 615
4.24 Vehicle to ground height mm 695
4.25 Distance between fork-arms b5 mm 540(685)
4.32
Ground clearance, center of
wheelbase
m2 mm 30
4.34.1
Aisle width for pallets 1000 ×
1200 crossways
Ast mm 2151
Technical data
9
Technical datasheet
895001 801 1555 EN - 12/2020
