Getting Started
IMPORTANT! Before AC power is applied to the SR-500, the plumbing
connection must be made properly. At the time of installation, or whenever the
plumbing has been reconfigured or changed in any way, the unit will need to perform
vacuum level measurements. At these times, the pool system must be as “perfect”
as it can be – drains unclogged, skimmers cleaned, etc., since the system will use
these vacuum measurements as a reference for all subsequent operation. After the
plumbing is complete and everything checks out “OK”, it’s time to apply power.
NOTE: Before applying power, make sure that voltage selector switch is set to
the correct AC line voltage – 115VAC or 230VAC.
When power is applied, the unit will perform a quick self-check and verify the
stability of the AC line. The unit will check the reference pressure values that were
set at the time of installation; if these values are not set, the unit will display the
error message “SET-UP REQUIRED.” Pressing and holding the SET button will put
the unit into the SERVICE MODE, intended for
use by service technicians only. Pressing any
other button will have no effect.
Once the clock is set and the pump is primed, the unit is ready for normal operation.
NOTE: The unit must be properly set-up in order to function: failing to
successfully perform the PRIME PUMP function will prevent the unit from
operating. Until the PRIME PUMP function is executed, you will continue to
see the ‘SET-UP REQUIRED’ message when you attempt to exit the SERVICE
MODE. No other operating modes may be selected.
SET-UP REQUIRED!
REFER TO MANUAL
17
