4
Use ANSI/ASME A112-19.8 approved Drain Covers
To prevent hair entrapment we STRONGLY recommend that you use
Anti-Entrapment drain covers that meet ANSI/ASME A112-19.8 standards.
Anti-Entrapment drain covers are only effective to a specific flow rate. To be sure
you are not exceeding the flow rate stamped on the cover, please contact your pool
builder or pool service professional.
Pr
essure
As used in this document, the term “pressure” can refer to positive pressure (above
atmospheric pressure) or negative pressure (vacuum below atmospheric pressure.)
Pr
ess a button
As used in this document, the term “press a button” means to momentarily press
then release the button. In cases where a button needs to be held, the instruction
will indicate this directly.
INSTALLATION
SR-500 Specifications
Technical Specifications – SR-500
Response Time: under 3 seconds from event detection
Enclosure: NEMA 3R (Intended for outdoor use. Provides a
degree of protection against falling rain and ice
formation. Meets rod entry, rain, external icing,
and rust-resistance design tests.)
Visual Alarm: Optional
Audible Alarm: 24V AC
Operating Environment: -40 to 140 degrees F (-40 to 60 degrees C),
0-95% RH,
Size: H = 9.0”; W = 5 1/2”; D =4.0”
Packaged Weight: 4 lbs.
T
echnical Specifications – Remote Alarm
Voltage: 24 V AC
Operating Environment: Suitable for Indoor\Outdoor
Size: H = 9.0”; Dia. = 3.0”
Weight: 1 lbs.
Note: Specifications subject to change without notice.
PROTECT HOSE IN FREEZING CONDITIONS!!!
If the pump is operated in an area where the ambient air temperature can fall below
32˚F, the hose must be protected from freezing by wrapping with heat tape.
