is complete, prime the pump by filling the trap with water, insure that all valves are set for nor-
mal operational, and clean the filter and all baskets. When the system is ready to operate, push
the YES button to start the pump, and the screen will read:
and the current running vacuum level is displayed. It is important at this time that the pump
achieve a full prime and is running normally to insure accurate calibration. If it takes more than
60 seconds for the pump to catch prime, hit the YES button again to restart the pump for anoth-
er 60 seconds. Once the pump is running at full head, and the vacuum level on the screen has
stabilized (1/2” to 1” of fluctuation is normal) press the YES button again WHILE THE PUMP
IS STILL RUNNING to immediately stop the pump and save the current vacuum values to the
memory.
The resting or stopped vacuum level will be
displayed.
If you see this error:
refer to the section “Troubleshooting calibration
issues”
Once the SR500 has saved the vacuum parameters,
the screen will read:
record this value for future reference. Push the SET
button, screen will read:
record this value for future reference. Push the SET
button, screen will read:
record this value for future reference. Push the SET
button, screen will read:
FULL PRIME? Y/N?
RUNNING XX.XX “Hg
PLEASE WAIT...
XX.XX”Hg
DELTA-P TOO LOW!
SET TO TRY AGAIN
REFERENCE VACUUM
DELTA-P XX.XX “Hg
REFERENCE VACUUM
STOPPED XX.XX “Hg
REFERENCE VACUUM
RUNNING “Hg
VACUUM CUTOFF AT
03” ABOVE REF Y/N?
21
