Installation (Cont.)
Fig. 4: Ventilation and cut-out requirements for the installation of the
appliance into a tall housing unit
50mm
Minimum ventilation
requirements for rear of
unit: top, base and support
shelves
Rear panel
Remove rear panel
from this section
Minimum ventilation
cut-out 200cm
2
Rear panel
Storage space
Plinth
Storage space
Fig. 4
85 + 90
85-90
VOID
50 MIN
