Stober PS6A24 - Fig. 4 Sticker with MV and Serial Number; Tab. 6 Meaning of the Specifications on the SI6 Nameplate; Tab. 7 Meaning of the Specifications on the Sticker

5 | System configuration STOBER
28
02/2019 | ID 442728.05
Designation Value in example Meaning
Types SI6A061 Device type according to type designation
ID No. 56645 Identification number of the basic device
HW 012 SAT Production information
Date 1712 Production week in format YYWW, in the example
shown here year 2017, week 12
S/N 9001043 Serial number
Input voltage 560V
DC
UL: 680V
DC
Input voltage
Input current UL: 4.2 A Input current
Output data 0 to 460V
AC
0 to 700Hz
@4kHz: 5.0A
3-phase
Output voltage
Output frequency
Output current for 4kHz clock frequency
Number of phases
Protection class IP20 Protection class
Tab. 6: Meaning of the specifications on the SI6 nameplate
Information
UL and cUL-certified devices with corresponding test symbols meet the requirements of the
standards UL 61800-5-1 and CSA C22.2 No. 274.
5.1.2.2 Material version
On the side of the drive controller next to the nameplate, there is another sticker with the MV
and serial number.
Fig.4: Sticker with MV and serial number
Designation Value in example Meaning
MV MV0000052345 MV number
SN SN: 600154723 Serial number
— SI6A061 Device type according to type designation
— 550007951/000100 Order number / order item
Tab. 7: Meaning of the specifications on the sticker
