6 | Technical data STOBER
44
02/2019 | ID 442728.05
6.3.1.3 Power unit: Size 1
Electrical data SI6A161 SI6A162
U
1PU
280–800V
DC
f
2PU
0–700Hz
U
2PU
0–max.
1PUU
2
C
PU
470µF 940µF
Tab. 27: SI6 electrical data, size 1
Nominal currents up to +45°C (in the control cabinet)
Electrical data SI6A161 SI6A162
f
PWM,PU
4kHz
I
2N,PU
12A 2×12A
I
2maxPU
210% for 2s
Tab. 28: SI6 electrical data, size 1, at 4kHz clock frequency
Electrical data SI6A161 SI6A162
f
PWM,PU
8kHz
I
2N,PU
10A 2×10A
I
2maxPU
250% for 2s
Tab. 29: SI6 electrical data, size 1, at 8kHz clock frequency
