6 | Technical data STOBER
56
02/2019 | ID 442728.05
Dimension DL6B10
DL6B20
DL6B11
DL6B21
DL6B12
Quick DC-Link Width w 45 65 105
Depth d1 35
Depth incl.
attachment bolts
d2 49
Height h1 375
Fastening clip height h2 15
Height incl.
fastening clips
h3 405
Fastening holes Vertical distance
(wall mounting)
a1 393+2
Vertical distance
(module mounting)
a2 360
Vertical distance to the
upper edge
b1 4.5
Vertical distance to the
upper edge
b2 22
Horizontal spacing of the
fastening holes
c — 45
Horizontal distance to the
side edge
g — 30
Tab. 47: DL6B dimensions [mm]
6.4.4 Weight
Type Weight without packaging [g] Weight with packaging [g]
DL6B10 420 460
DL6B11 560 600
DL6B12 920 960
DL6B20 480 520
DL6B21 740 780
Tab. 48: DL6B weight [g]
