- 61 -
Parts List
Item Part No. Description Qty.
1285PM & 1650PM Clutch Assembly
1 32146 Release Bearing (incl 2 HHCS 5/16 - 24 X 1 - 3/4/2 NUTNY 5/16 - 24) 1
4 32147 Adjustable Ring 1
5 32148 Release Sleeve 1
6 80533 PINCT 1/16 X 3/8 9
7 32185 Pin Clevis 3
8 32184 Connecting Link 6
9 32189 Roller Lever 3
10 32235 Release Sleeve/Lever 6
11 32188 Pin Clevis 3
12 32190 Pin Clevis 3
13 32149 Pressure Plate Assy 1
14 30121 Clutch Disc Rockford 1
15 32183 Spring 3
16 32182 Ball Bearing 1
17 80534 SLTD HHCS 1/4 - 20 X 3/8 1
18 80116 WSHRL 1/4 ZN 1
19 32191 Lock Adjusting 1
20 80242 NUTFX 3/8 - 24 2
21 80058 WSHRL 3/8 ZN 2
22 32150 Housing Clutch 1
23 38123 Lock Tab 2
24 80535 HHCS 3/8 - 24 X 2 - 1/2 2
25^ 46042 Grease Fitting 1
Note: ^ Not Shown
