StoneL Quartz QX Series User Manual

7 QZ 70 en6 | Quartz
StoneL publication 105406revA
1.8 Dimensions
SEE NOTE 1
3.4
[0.14 in]
17.6
[0.69 in]
153.9
[6.06 in]
38.9
[1.53 in]
16.1
[0.63 in]
19.1
[0.75 in]
45°
∅7.1
[0.28 in]
(2)
11.3
[0.44 in]
38.1
[1.50 in]
82.6
[3.25 in]
18.2
[0.72 in]
6-32 PAN HEAD SCREW
∅4.0
[0.16 in]
PINS (2)
SEE NOTE 1
3.4
[0.14 in]
31.8
[1.25 in]
119.4
[4.70 in]
14.2
[0.56 in
]
Note 1
Cover height varies based on model number.
Dual module and 2-switch models use short covers.
Short cover = 102 mm [4.0 in]
Medium cover = 123.4 mm [4.86 in]
Tall cover = 155.4 mm [6.12 in]
Quartz certied dimensional drawing can be found under
the download tab at www.stoneL.com/en/products/Quartz
Output option “S” - Short visual indicator
Output option “N” - Extended visual indicator
