Annex A – Cable cross reference tables
This table shows a list of existing cables that can be used with Optimo when used in conjunction with the
appropriate adaptor cables supplied. Note: only A8 for Optimo Light
Part Number
Description
Cable
Identification
Current Din
Connector
Adaptor A
or B
7780-981
Tachograph Drive Lead
CABLE C
6 way
A-6
7780-982
Vehicle Sender Conn. Lead
CABLE D
6 way
A-6
7780-983
PPR/Engine Rev Calibration
Lead
CABLE E
6 way
A-6
7780-986
Serial Data Out Adaptor
Lead
CABLE F
Use with Cable H
A-4
7780-984
Jack Socket Connection
Lead
CABLE G
6 way
A-6
7780-989
Serial Data Conn Lead
CABLE H
4 way
A-4
7780-987
Adaptor Cable (1400)
CABLE K
6 way
A-6
7780-988
Adaptor Cable (1314)
CABLE L
6 way
A-6
7780-974
Motometer Pulser Adaptor
CABLE M
Use with Cable C
A-6
7780-980
Motometer Programming
Lead
CABLE N
8 way
A-8
7780-979
1319 Jack Socket Adaptor
Lead
CABLE O
Use with Cable G
A-6
7780-973
1319 Programming Lead
CABLE P
8 way
A-8
7780-975
Motometer Revs Adaptor
CABLE Q
Use with Cable G
A-6
7780-978
Flat Wire Cable Adaptor
8400
CABLE S
Use with Cable G
A-6
7780-977
Flat Wire Cable Adaptor
1314
CABLE T
Use with Cable H
A-4
7780-936
2400 Programming Lead
CABLE U
8 way
A-8
7780-956
2400 Canbus Data Lead
CABLE V
8 way
A-8
7780-952
MTCO Programming Lead
CABLE W
8 way
A-8
7780-955
2400 Serial Data Adaptor
Lead
CABLE X
Use with Cable H
A-4
7780-810
Digital Programming Lead
CABLE Z
8 way
A-8
7955-938
Clock Tester
8 way
A-8
7955-777
Flexi Switch
4 way
B
7780-948
Kienzle Laser Device
Adaptor
4 way
B
7500-008
Rolling Road Cable
4 way
B
