Stonex SC600 GNSS Receiver – User Manual
11
3. Operation
3.1 Power ON/OFF
SC600 will power on automatically after it connects the 2-pin power cable and have power supply.
And after it powered on, the indicators will show the device status. For example, the power indicator will light red. And if
the WIFI is on, the WIFI will light green.
After the SC600 don’t have power supply, it will power off.
3.2 Insert Cards
If you need to use the SIM card, you should insert the SIM card before you power on the SC600.
Please see the below picture, open the card cover first, then insert the SIM card and micro SD card as the notes in card
cover.
3.3 Connect external accessories
In order to reach the work status, the SC600 should connect the external antenna, you can connect the external antenna to
the GNSS1/2.
If you need to use the SIM card, you should insert the SIM card and connect the 4G antenna to the LTE connector.
If you need to use the radio, you should connect the UHF antenna to the UHF connector.
